Home Doppler Ultrasound Portable Diagnostic Hand held Doppler Ultrasound Obstetric Gynecology Pediatrics Application

Brand Name : BIO

Model Number : W4

Place of Origin : China

MOQ : 1 unit

Packaging Details : Carton (240x235x100mm), 1.1Kgs/carton

Payment Terms : Credit card, Paypal, T/T

Delivery Time : 7 working - days since getting full payment

Supply Ability : 100 units / month

Type : Linear, Convex and so on

Connection Way : Wi-Fi

Elements : 128

Frequency : Linear: 7.5-10MHz Convex: 3.5-5MHz

Supporting System : Andriod, Windows, IOS

Measurement : B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL) B+M: Heart Rate, Time, Distance B+PW: Velocity, Heart Rate (2), S/D, Depth

Display Mode : B, B/M, Color Doppler, PW, Power Doppler

Weight : 221g

Contact Now

Home Doppler Ultrasound Portable Diagnostic Hand held Doppler Ultrasound

Obstetric Gynecology Pediatrics Application

W4 Ultrasound Scanners are wireless and working with a mobile app that is compatible with most iOS and Android smart devices

as well Windows system. Imaging transmission is done by internal 5G wifi , no external networks needed and work for most specialties

in hospitals , clinics, healthcare center etc.

We are a medical ultrasound company engaged in R&D , production, sale and after-sales service.

We persistently cooperated closely with domestic and international famous medical ultrasound R&D organization

and keep in contact with related university ,labs professors and doctors to update latest data of ultrasound machines ,

also professional clinical applications experience.

Specification

Item	1	2	3	4	5	6
Type	Linear	Convex	Linear	Micro convex	Linear	Endocavitary
Frequency	7.5-10MHz	3.5-5MHz	7.5-10MHz	5-7MHz	10-14MHz	6.5-8MHz
Depth	20-55mm	90-305mm	20-100mm	60-160mm	20-100mm	30-120mm
Elements	128	192	192	192	192	192
Radius	N/A	R60	N/A	R20	N/A	R10
Length	46mm	N/A	46mm	N/A	28mm	N/A
DR	N/A	40-100	40-100	40-100	40-100	40-100
FocusPos	N/A	0.1.2.3	0.1.2.3	0.1.2.3	N/A	0.1.2.3
Enh	0-4	0-4	0-4	0-4	0-4	0-4
Display mode	B, B/M, Color Doppler,PW, Power Dopper	B, B/M, Color Doppler,PW, Power Dopper	B, B/M, Color Doppler,PW, Power Dopper	B, B/M, Color Doppler,PW, Power Dopper	B, B/M, Color Doppler,PW, Power Dopper	B, B/M, Color Doppler,PW, Power Dopper
APP interface adjustment	GN(gain) D(depth) ENH(enhancement) DR(dynamic range) F(frequency) Focus 8TGC Biopsy Page Left/Right Up/Down	GN(gain) 8TGC D(depth) ENH(enhancement) DR(dynamic range) F(frequency) PRF WF Focus Biopsy Page Left/Right Up/Down	GN(gain) 8TGC D(depth) ENH(enhancement) DR(dynamic range) F(frequency) PRF WF Focus Biopsy Page Left/Right Up/Down	GN(gain) 8TGC D(depth) ENH(enhancement) DR(dynamic range) F(frequency) PRF WF Focus Biopsy Page Left/Right Up/Down	GN(gain) 8TGC D(depth) ENH(enhancement) DR(dynamic range) F(frequency) PRF WF Focus Biopsy Page Left/Right Up/Down	GN(gain) 8TGC D(depth) ENH(enhancement) DR(dynamic range) F(frequency) PRF WF Focus Biopsy Page Left/Right Up/Down
Measurement	B: Length, Area/Circumference, Angle,Trace,Distance B+M: Heart Rate, Time, Distance B+PW: Velocity, Heart Rate (2), S/D, Depth	B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL) B+M: Heart Rate, Time, Distance B+PW: Velocity, Heart Rate (2), S/D, Depth	B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL) B+M: Heart Rate, Time, Distance B+PW: Velocity, Heart Rate (2), S/D, Depth	B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL) B+M: Heart Rate, Time, Distance B+PW: Velocity, Heart Rate (2), S/D, Depth	B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL) B+M: Heart Rate, Time, Distance B+PW: Velocity, Heart Rate (2), S/D, Depth	B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL) B+M: Heart Rate, Time, Distance B+PW: Velocity, Heart Rate (2), S/D, Depth
Dimensions	157(h)70(w)30(d)mm	157(h)70(w)30(d)mm	157(h)70(w)30(d)mm	157(h)70(w)30(d)mm	157(h)70(w)30(d)mm	345(h)70(w)30(d)mm
Package size	240(h)235(w)100(d)mm	240(h)235(w)100(d)mm	240(h)235(w)100(d)mm	240(h)235(w)100(d)mm	240(h)235(w)100(d)mm	540(h)120(w)100(d)mm
Net weight	221g	239g	223g	221g	212g	293g
Gross weight	1.1kgs	1.1kgs	1.1kgs	1.1kgs	1.1kgs	1.1kgs
Wifi type	802.11g/20MHz/2.4G	802.11g/20MHz/2.4G	802.11g/20MHz/2.4G	802.11g/20MHz/2.4G	802.11g/20MHz/2.4G	802.11g/20MHz/2.4G
Working system	Android, iOS, Windows	Android, iOS, Windows	Android, iOS, Windows	Android, iOS, Windows	Android, iOS, Windows	Android, iOS, Windows
Application	Breast Thyroid MSK Superficial Vascular Pediatrics Carotid Small Parts	Abdominal Emergency Cardiac Obstetrics / Gynecology Lung Kidney Urology	Thyriod Small Parts Pediatrics Vascular Carotid Breast MSK	Abdominal Emergency Cardiac Obstetrics / Gynecology Lung Kidney Urology	Thyriod Small Parts Pediatrics Vascular Carotid Breast MSK	Abdominal Emergency Cardiac Obstetrics / Gynecology Lung Kidney Urology
Language	Chinese,English,Russian,Italian, Spanish,Portuguese(Brazil)	Chinese,English,Russian,Italian, Spanish,Portuguese(Brazil)	Chinese,English,Russian,Italian, Spanish,Portuguese(Brazil)	Chinese,English,Russian,Italian, Spanish,Portuguese(Brazil)	Chinese,English,Russian,Italian, Spanish,Portuguese(Brazil)	Chinese,English,Russian,Italian, Spanish,Portuguese(Brazil)
Battery life	5-8 years	5-8 years	5-8 years	5-8 years	5-8 years	5-8 years
Voltage	3.8v	3.8v	3.8v	3.8v	3.8v	3.8v
Replaceable	Yes	Yes	Yes	Yes	Yes	Yes
Capacity	4200mAh	4200mAh	4200mAh	4200mAh	4200mAh	4200mAh
Standby	12h	12h	12h	12h	12h	12h
Bootup	Platform dependent, generally <5 seconds	Platform dependent, generally <5 seconds	Platform dependent, generally <5 seconds	Platform dependent, generally <5 seconds	Platform dependent, generally <5 seconds	Platform dependent, generally <5 seconds

Standard Configuration

1	Wireless probe	1pc
2	USB cable	1pc
3	Power Plug	1pc
4	Wireless charger	1pc
5	Wrist strap	1pc
6	Portable aluminium alloy box	1pc
7	User's Manual_E format	1pc
8	Warranty Card_Eformat	1pc
